Air bag deactivation switch, frontal, passenger-side (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner’s Manual for more information.) |
| • |
Air bags, frontal, driver and right-front passenger (Included with (ZX2) driver and front passenger high-back bucket seats. Not available with (ZX1) driver only high-back bucket seat. Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner’s Manual for more information.) |
| • |
Air conditioning, single-zone manual |
| • |
Assist handles, driver and right-front passenger |
| • |
Audio system, AM/FM stereo with MP3 player seek-and-scan, digital clock, TheftLock, random select, auxiliary jack and 2 front door speakers (Not available with (YF1) RV Package.) |
| • |
Battery, 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power |
| • |
Brake/transmission shift interlock for automatic transmissions |
| • |
Brakes, 4-wheel antilock, 4-wheel disc |
| • |
Bumper, front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package or (YF1) RV Package is ordered.) |
| • |
Cup holders, 3 on the engine console cover |
|
| • |
Driver Information Center includes fuel range, average speed, oil life, fuel used, ice warning, engine hours, average fuel economy, tachometer and maintenance reminders. |
| • |
Engine, Vortec 4.8L V8 SFI (285 hp [212.5 kW] @ 5400 rpm, 295 lb-ft of torque [398.3 N-m] @ 4600 rpm) (Standard on the CG33503 and CG33803 models. With CG33503 requires (C4M) 9900 lbs. (4490 kg) GVWR or (9N2) 10,050 lbs. (4559 kg) GVWR. With CG33803 model requires (9N2) 10,050 lbs. (4559 kg) GVWR or (JFF) 10,100 lbs (4581 kg) GVWR. Not available on the CG33903 model. Not available with (YF1) RV Package, (ANC) Shuttle Bus Package or (C7N) 12,300 lbs. (5579 kg) GVWR. Not available with (ENC) HVAC system auxiliary rear heat provisions on CG33803 models. Includes external engine oil cooler. Reference the Engine/Axle page for availability.) |
| • |
Exhaust, aluminized stainless-steel muffler and tailpipe |
| • |
Flasher, heavy duty light emitting diode (LED), formerly known as SEO (8H9) |
| • |
Floor covering, Black rubberized-vinyl front |
| • |
Fuel tank capacity, mid-frame and approximately 33 gallons (124.9L) |
| • |
Grille, Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.) |
| • |
GVWR, 9900 lbs. (4490 kg) (Standard on the CG33503 model. Available on the CG33803 model. Requires (R04) single rear wheel configuration. Not available with (R05) dual rear wheel configuration. Reference the Engine/Axle page for availability.) |
| • |
Headliner, cloth, over driver and passenger |
| • |
Heater and defogger with front and side window defoggers |
| • |
Incomplete vehicle certification |
| • |
Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure |
|
| • |
License plate kit, front |
| • |
Lighting, interior with dome light and door handle-activated switches |
| • |
Mirrors, outside delete (Not available with (5Q7) Upfitter option Blank Sail Panel Delete when ordered with (YF2) Ambulance Package.) |
| • |
Power outlets 2 auxiliary on engine console cover with covers, 12-volt |
| • |
Rear axle, 3.42 ratio (Requires CG33503 or CG33803 model and (L20) Vortec 4.8L V8 SFI engine or (L96) Vortec 6.0L V8 SFI engine and (C4M) 9900 lbs. (4490 kg) GVWR or (JFF) 10,100 lbs. (4581 kg) GVWR.) |
| • |
Seating arrangement, driver and front passenger highback bucket includes head restraints and vinyl or cloth trim (Not available with (AJ3) driver-side only frontal air bag.) |
| • |
Seats, front bucket with vinyl trim and head restraints includes inboard armrests (Requires (**W) trim. Not available with SEO (ZP0) delete driver and passenger seats. Includes only driver high-back bucket seat with vinyl trim when ordered with (ZX1) driver-only high-back bucket seating arrangement.) |
| • |
Suspension, front independent with coil springs and stabilizer bar |
| • |
Suspension, rear hypoid drive axle with multi-leaf springs |
|
| • |
Theft-deterrent system, vehicle, PASS-Key III |
| • |
Tire Pressure Monitor System (does not monitor spare tires) (Required with (C4M) 9900 lbs. (4490 kg) GVWR and (R04) single rear 4 - 16 x 6.5 (40.6 cm x 16.5 cm) wheels. Not available with CG33803 models or CG33903 models.) |
| • |
Tires, front LT245/75R16E all-season, blackwall (Included and only available with CG33503 or CG33803 and (C4M) 9900 lbs. (4490 kg.) GVWR or (JFF) 10,100 lbs. (4581 kg.) GVWR and (R04) single rear wheel configuration. Jack and spare tire equipment bracket are not included.) |
| • |
Tires, rear LT245/75R16E all-season, blackwall (Included and only available with CG33503 or CG33803 and (C4M) 9900 lbs. (4490 kg.) GVWR or (JFF) 10,100 lbs. (4581 kg.) GVWR and (R04) single rear wheel configuration. Jack and spare tire equipment bracket are not included.) |
| • |
Tow/haul mode selector, instrument panel-mounted |
| • |
Transmission oil cooler, external |
| • |
Transmission, 6-speed automatic, heavy-duty electronically controlled with overdrive and tow/haul mode and internal transmission oil cooler (Reference the Engine/Axle page for availability.) |
| • |
Visors, driver and front passenger, cloth, padded |
| • |
Warning tones, headlamp on and key-in-ignition |
| • |
Wheel configuration, rear, single (Standard on CG33503 model. Available on CG33803 model. Not available with (9N2) 10,050 lbs. (4559 kg.), (C7N) 12,300 lbs. (5579 kg.) GVWR or (C7I) 14, 200 lbs. (6441 kg) GVWR.) |
| • |
Wheels, 4 -16 x 6.5 (40.6 cm x 16.5 cm), 8-lug painted steel, heavy-duty (Only available with (R04) single rear wheel configuration.) |
| • |
Wipers, front intermittent wet-arm with pulse washers |
|
